Erhardt K System | One product many possibilities

Elegant | High-Performance | Modern | Award Winning

No-one wants problems when they’re trying to relax and enjoy their free time on their terrace or balcony – after all, quality time is precious. The ERHARDT K cassette awning is the perfect choice if you’re looking for maximum protection for your awning fabric, as the fabric and the entire arm mechanism can be retracted and stored in a fully enclosed cassette.

Erhardt K stock button

The Erhardt K is a small cassette awning from German manufacturer Erhardt Markisen that excels in being installed in difficult scenarios, due to an installation height of only 13cm. For this reason it is the ideal awning for installations that take place on balconies or terraces. The compact design helps the awning to be installed into even the tightest of spaces by making use of the multiple different mounting options.

The full cassette helps to protect the fabric awning as well as the mechanism when it is fully retracted. This helps to ensure maximum protection from the elements and when combined with the small nature of the cassette, it ensures an unobtrusive and subtle aesthetic.


The Erhardt K comes with a motor as standard, and this can help make the awning effortless to operate. Just the push of a button can transform your patio or balcony area.

The Erhardt K is available with many different extras and options. The awning can be automated through the use of a motor and remote control, which when combined with a sun and wind sensor can create a truly hassle free awning with maximum ease of use.

Also available are light bars and infrared heaters, both of which can be dimmed. This allows you to enjoy your outside space for far longer into the evening when both heat and visibility would ordinarily become an issue, as well as further into the colder and darker autumn and winter months.

Technical details

Maximum dimensions: 500 x 300 cm (width x projection)

Cassette awning: Cloth Roll Protected mechanism and fabric shaft

Frame colour: White (RAL 9016), Grey aluminium structured (RAL 9007 finely structured), Anthracite (DB 703)

Fabric designs:

Tibelly Ambient collection (polyester)

Tibelly Classic collection (acrylic)

Inclination angle: 0-45° with motor; 0-30° with crank


Ceiling mounting

Wall mounting

Special features:

Ideal for balconies and small terraces

Motorised as standard

Low installation height, cassette height only 13 cm

Simple design


Remote control

Automatic wind and sun control

Somfy Eolis wireless oscillation sensor

Awning fabric with welding adhesive technology

LED strip in cassette housing dimmable, optional external transformer in cable channel

Infrared heater (including wireless level control)

How can I order? Our approach

For many years we’ve helped our domestic and commercial awning and canopy customers.

How can I order? Our approach

1. Take several pictures of the area where you are looking to create an outdoor space.
2. Send your images with your details.
3. Tell us a little about what you want to achieve e.g. sun protection, rain protection, all year round use of space and so on.
4. If you have any preferences already, things such as retractable, fixed or both in one system. Don’t worry if you haven’t as we can advise and guide you later if needed. Read more

Email us today or call us on 01933 448 844 to discuss your requirements.
